Datalogic Quickscan I LITE QW2400

The QuickScan Lite QW2400 2D area imager is an entry level scanner specifically designed for reading long and truncated 1D codes and larger 2D codes from close distance.  The QW2400 imager has an extra-wide Field of View (FOV) which captures these challenging 1D and 2D codes at a nominal distance using different scan angles, meeting the scanning needs in Retail, Light Manufacturing, Document/Bill Processing and Banking/Finance.  The QuickScan Lite 2D imager is the most affordable area imager with the best performance in its class.

Description

Print Specification

  • Resolution:8 dots/mm (203 DPI)
  • Max print speed: 356 mm (14″)/second
  • Max print width: 104 mm (4.09″)
  • Max print length: 25,400 mm (1,000″)
  • Printing method: Thermal Transfer & Direct Thermal

LCD/LED

  • TFT color display, 320 x 240 pixels & 1 LED with 3 colors (red, green, amber)

Memory

  • SDRAM:128 MB
  • Flash:128 MB
  • Extension:micro SD Flash memory card reader for Flash memory expansion, up to 32 GB
  • Ribbon capacity: 600 m long, max. OD 90 mm, 1″ core (ink coated outside or inside)
  • Ribbon width: 4 mm ~ 114.3 mm (1″ ~ 4.5″)
  • Media type: Continuous, die-cut, black mark, fan-fold, notch (outside wound)

Physical Characteristics

    • Dimension:276 mm (W) x 326 mm (H) x 502 mm (D)
      87″ (W) x 12.83″ (H) x 19.76″ (D)
    • Weight:35 kg (33.84 lbs)

Ribbon & Media Capacity

  • Ribbon capacity: 600 m long, max. OD 90 mm, 1″ core (ink coated outside or inside)
  • Ribbon width: 4 mm ~ 114.3 mm (1″ ~ 4.5″)
  • Media type: Continuous, die-cut, black mark, fan-fold, notch (outside wound)
  • Media width: 20 ~ 114 mm (0.79″ ~ 4.5″)
  • Media thickness: 06 ~ 0.28 mm (2.36 ~ 28 mil)
  • Media core diameter: 1 ~ 76.2 mm (1.5″ ~ 3″)
  • Media length: 5 ~ 25,400 mm (0.20″ ~ 1,000″)
  • Media roll capacity: 2 mm (8″) OD

Interface

  • Standard:
  • USB 2.0
    • RS-232
    • Ethernet
    • 10/100 Mbps
    • USB Host
  • Options:
  • GPIO + Parallel
    • internal Bluetooth
    • 802.11 a/b/g/n Wi-Fi

Software support

  • SAP, Oracle, WHQL 8.1, Windows, Linux, MAC X.10, Mircosoft SQL Server, Bartender, Nice Label
